This Pulse Converter is used with our MAG series magnetic inductive flow meters and the ABC-2020 Batch Controller. It takes the active voltage pulses from the meter and converts that to a simple contact closure similar to a reed switch. It is a solid state switch that closes whenever voltage is applied.
The pulse converter can be used with other meters having an M12 connector with the same wiring pin-out. Check with Flows.com to verify the compatibility with any given meter. The wiring harnesses can be customized if needed for any meter with an active voltage type pulse output.
The wiring harness has 3 ends:
- A Standard US wall outlet plug with a 24VDC transformer
- A 2-pin push-in connector to connect to the :meter" port on the ABC-2020 controller
- An M12 connector that connects to the MAG meter providing power to the meter and accepting the active voltage pulse output
